Innovative Glazed Glass Partition With Aluminum Frame for Soundproof Office Meeting Room

Innovative Glazed Glass Partition With Aluminum Frame for Soundproof Office Meeting Room

Quantity:
Availability:





Inquire Add to Basket

Glass Partition With Aluminum Frame For Soundproof Office Meeting Room aluminum Framed Glass Partiti

Product Description

Product Name	56 Glass Partitions
Specification And Model	56-DB
Metal Frame	Internal Steel And External Aluminum Gb6063-T5
Load Bearing Material	Double Layered Steel Keel; Roll Riveting; Thickness 1.8-2.5mm
Spraying Method	Electrostatic Spray
Upper And Lower Frames	Height 30mm; Thickness 1.8-2.5mm
Gate Post	Thickness 3.0mm
Width Between Glasses	Width 1mm; Transparent Adhesive 3m
Interlayer	Transparent Acrylic; Imported Thickness 1mm; 3m Transparent Adhesive
Glass Thickness	Single Glass 12mm
Cutting Deviation	Diagonal ± 0.5mm
Glass Material	Ultra White Glass; Frosted Surface; Tempered Glass; Glass
Metal Surface Treatment	Rust Proof
Equipment Belt	0.8mm Thick Steel Plate; Lined With 12mm Gypsum Board; 0.2mm Thick Steel Corrugated Board; Thickness of Finished Product 13mm
Installation Process	Assemble Type
Packaging Method	Box
Supply Cycle	10-15 Days
Mode of Transport	Highway And Sea Transportation
After-Sale Service	After Sales Guarantee for 5 Years

1.We calculate the price by square meter , however, it has a variation in price for every single project. Four key factors influence pricing :
1) Material & design Selection;
2) Hardware choice;
3) Partition width & height ;
4) Acoustic performance requirement.

2. What materials can be selected for office Aluminium partition wall ?
We have different types with single / double glazed or solid panels, glass can be clear tempered glass, frosted glass, painting glass, smart glass etc..Solid materials can be melamine laminate, HPL, Aluminium board, Steel plate.

3. How easy is it to install or remove a framed glass partition?
It's 100% removable and reusable. All modular parts will be pre-assembled in our factory, what you need to to is follow sequence to fix materials over flooring and under gypsum ceiling . We have detailed installation video from A to Z, we can also provide supervisor in site to install if you need.

4. How do they compare to drywall?
1) Office glass partition systems are more cost-effect.
2) Install easier and more faster than drywall.
3) Panels can be removed and reconfigured to fit other areas.
4) Provide the better Sound Transmission Class ratings than drywall.
5) Noble and elegant appearance by various design.
